TIPS
GENERAL
We recommend taking a bracket with you when you purchase your wood to test fit.
WOOD
Our 4x4 brackets accommodate dressed lumber, commonly called 4x4’s at local building supplies. The actual measure is 3.5x3.5”.
Our 6x6 brackets accommodate dressed lumber, commonly called 6x6’s at local building supplies. The actual measure is 5.5x5.5”.
SCREWS
- Each bracket only requires 3 screws per each side/set of three holes.
- Insert screws in holes closest to the wood.
- Hardware to secure to wood is included.
- Additional screws are available for purchase
INCLUDED
- 4x TRIO corner brackets
- 6x SOLO base/wall brackets
- 2x QUAD extension bracket
- Screw kit (enough screws for your use)
NOT INCLUDED
- Wood
Shipping wood is costly. Most of the population has access to stores that sell wood locally where they live. Buying your lumber allows you the freedom to select the type of wood you want to use for your build and budget. There are also regional limitations for what kind of lumber is ideal for your build; different species of lumber would be used in tropical climate vs. a cold one. - Anchoring Hardware
Due to different building materials and requirements based on location, we advise on checking building codes and talking to your local hardware store for the best securing hardware for your specific surface.
SINGLE ANY SIZE PERGOLA BUILD
WHAT YOU NEED
Drill(s)
Measuring Tape
Cardboard (to be placed under the brackets to not scratch your surface or the brackets)
LUMBER
When purchasing your lumber, always take a bracket with you to ensure a proper fit.
You can select whatever lumber suits your style and budget. It must be dry and straight.
Brackets use dressed lumber.
4”x4” (3.5”x3.5”) Bracket Cavity is 3.61”x3.61”
6”x6” (5.5”x5.5”) Bracket Cavity is 5.62”x5.62”
SCREWS
Each bracket only requires 3 screws per each side/set of three holes.1-1/2” Pan Rob/Phil combo drive wood screws with Black plastic head caps are included.
Insert screws in holes closest to the wood.
Hardware to secure to wood is included.
Additional screws are available for purchase.SECTION 1 BUILDING THE TOP
BUILDING A ‘U’: Insert your lumber into the brackets, creating a U. See figure 1.
BUILDING AN ‘I’: Insert your lumber into the remaining brackets. See figure 2.
Secure bracket to lumber with provided screws.
SECTION 2 INSERT THE POSTS
Insert your vertical posts on the first side.
Secure bracket to lumber with provided screws.
SECTION 3 INSERT THE POSTS
Add vertical posts into QUADs.
Secure bracket to lumber with provided screws.
The first half of the double pergola has now been built.
SECTION 4 BUILDING THE SECOND SIDE
Insert lumber into the second side.
Secure bracket to lumber with provided screws.
SECTION 5 COMPLETE
Lift and slide into the first side.
Secure bracket to lumber with provided screws.
Anchor to your surface. Remember Anchoring hardware is NOT included as surfaces will vary from build to build. A local building supply retailer will be a helpful resource.
Any Size Pergola Kit for Wood Posts
Build to your space with the freestanding pergola kit today!
Jurrque: Ensure lumber is fully inserted into the bracket cavity, resting on metal tabs for proper installation.
